Extrusion PSA Tapes

The extrusion process can be used for producing anything from weatherstripping to wire insulation components. No matter what kinds of applications you're working on, Magnum Tapes & Films® is your go-to source for double-coated extrusion tape. Our high-performance tapes deliver the aggressive adhesive and exceptional adhesion properties you need.

Request Samples   Call Us   Contact Us

Magnum Tapes and Films high performance tapes for RV campers automative and building construction applications

About Our Extrusion PSA Tapes

Pressure-sensitive adhesive (PSA) tapes are designed to hold two surfaces together through contact. By applying external pressure to the tape, it's able to form a bond. This allows it to adhere to all kinds of extrusion applications involving materials like:

  • Metals
  • Wood
  • Plastics
  • Papers
  • Glass
  • EPDM rubber

Because of the way they're designed, extrusion PSA tapes can work well for either permanent or removable applications. No matter what your needs may be, this tape lets you get the job done.

400 Series

The 400 series offers a permanent solution for rough or irregular applications. It works exceptionally well when used for bonding to polyisoprene, abrasive pads and papers, polyethylene, and more, delivering an excellent initial tack. In applications where you need versatility, dimensional stability, and die-cutting performance, the 400 series will provide the exact properties you're looking for.

500 Series

Our 500 series works especially well for bonding materials like rubber and EPDM foams. This versatile solution features a thick adhesive, which makes it especially effective for rough surfaces. It delivers an initial tack and offers exceptional dimensional stability when die-cutting.

Benefits of Extrusion PSA Tape

Our line of PSA tape is designed to be incredibly versatile to suit an array of applications. Because they're double-sided, these adhesive tapes can work well for numerous applications.

Whether you need an abrasive tape for metal or another material, this tape is designed to be pressure-sensitive. As long as you apply enough pressure, it should stick to all kinds of surfaces. Whether you use it for electrical work or as heat containment, this tape can do it all.

Along with serving well for all kinds of functional purposes, extrusion PSA tape can also be used to simply add to an object's aesthetic appeal.

Why Trust Us for Your Adhesive Needs?

As a full-service commercial tape and film manufacturer, Magnum Tapes & Films® is well-equipped to handle all your needs, including your most challenging projects. Since 1991, we've been a proud supplier of top-performing tapes and films. Whether you need bonding tape for paper or metal, you can count on us to carry out our Magnum® promise—quality, service, delivery, and value.

We rely on our state-of-the-art facility and solutions to deliver products that are both top-quality and responsive. With our quality control measures, we ensure our extrusion PSA tapes will stand up to the job. This, plus our commitment to continuously improving the products we provide, means we are always ready to adapt to your industry's changing needs.

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
400 Series

R-435

PDF

60#
SCK
2.6 mil
400 Series Permanent Rubber
0.5 mil Clear PET 2.6 mil
400 Series Permanent Rubber
Versatile permanent rubber tape. Ideal for rough or irregular surfaces where heavy adhesive thickness is required. Premium product for irregular and rough surfaces. Excellent bonding to polyethylene, polyisoprene, polystyrene, polypropylene, EPDM rubber, metals, and papers, including abrasive papers. Good dimensional stability with excellent die-cutting performance. Very high shear properties and high peel performance with excellent initial tack.

R-449

PDF

60#
SCK
2.1 mil
400 Series Permanent Rubber
0.5 mil Clear PET 1.4 mil
400 Series Permanent Rubber
Permanent pressure-sensitive double-coated general-purpose rubber tape with excellent peel and shear performance. Airside provides a thicker glue coating for rougher surface applications. Typically used for bonding to paper, metal, EPDM rubber, polyisoprene, plastics, abrasive pads, and most low- or unplasticized substrates. The polyester carrier provides excellent dimensional stability for die-cutting applications.
500 Series

R-501

PDF

60#
SCK
1.4 mil
500 Series Permanent Rubber
0.5 mil Clear PET 1.4 mil
500 Series Permanent Rubber
Versatile foam bonding adhesive. Excellent for bonding polyethylene, rubber, and EPDM foams. Aggressive initial tack with excellent peel and surface wet-out. Thicker adhesive for rough surfaces. PET carriers provide good dimensional stability in die-cutting. Standard layflat liner.
*The most common liner is listed for each configuration; additional liners are available.



Contact Our Team to Learn More

When you need a commercial extrusion PSA tape manufacturer, turn to Magnum Tapes & Films®. We are here to answer your questions and help you determine the best tape for your application. Contact us today at 877-460-8402 or reach out online to request a project quote.
