Magnum Tapes and Films Graphic Mounting Tapes



Magnum Tapes and Films Adhesive Product Guide Specifications and Qualifications

Graphic PSA Tapes

Magnum Tapes & Films® manufactures mounting tapes for graphic arts, digital printing, POP displays, and wide format mounting. Magnum’s adhesive tapes are designed for quality and long-lasting performance for demanding image mount applications. Our Low VOC Acrylic tapes have been emissions tested and meet JIS-A 1901 standard and ISO 18916 for photographic archiving. Our tapes are also acid-free for general archival applications.

Magnum Tapes and Films Graphic Mounting PSA Tapes

Magnum GraphicMount™ tapes are used in the digital imaging and graphic arts industry for print brightening and mounting to many types of boards, including Gator Foam,® Gator Board,® Sintra,® and LSE plastics. With tapes identified by Economy, Standard, and Premium, we make it easy to find the tape for your application and budget. Available in multiple widths on a layflat liner with either a white or clear carrier.

DOUBLE-COATED TAPES

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
300 Series

R-382

PREMIUM

PDF

76#
PCK
1.1 mil
300 Series Permanent Rubber
1.0 mil Clear PET 1.1 mil
300 Series Permanent Rubber
Magnum GraphicMount™ R-382 tape is an aggressive premium self-wound, double-coated polyester film on a 76# poly-coated paper liner. The transparent polyester carrier film is coated on both sides with an aggressive rubber pressure-sensitive adhesive. Available in a variety of stock widths.

R-392

PREMIUM

PDF

76#
PCK
1.1 mil
300 Series Permanent Rubber
1.4 mil White PET 1.1 mil
300 Series Permanent Rubber
Magnum GraphicMount™ R-392 tape is an aggressive premium self-wound, double-coated polyester film on a 76# poly-coated paper liner. The white polyester carrier film is coated on both sides with an aggressive rubber pressure-sensitive adhesive. Available in a variety of stock widths.
400 Series

R-431

ECONOMY

PDF

76#
PCK
0.8 mil
400 Series Permanent Rubber
0.5 mil Clear PET 0.8 mil
400 Series Permanent Rubber
Magnum GraphicMount™ R-431 tape is our economy self-wound, double-coated polyester film on a 76# poly-coated paper liner. The clear polyester carrier film is coated on both sides with a permanent rubber pressure-sensitive adhesive. Available in a variety of stock widths.

R-482

STANDARD

PDF

76#
PCK
1.1 mil
400 Series Permanent Rubber
1.0 mil Clear PET 1.1 mil
400 Series Permanent Rubber
Magnum GraphicMount™ R-482 tape is our economy self-wound, double-coated polyester film on a 76# poly-coated paper liner. The clear polyester carrier film is coated on both sides with a permanent rubber pressure-sensitive adhesive. Available in a variety of stock widths.
800 Series

A-882

PREMIUM

PDF

76#
PCK
1.1 mil
800 Series Permanent Low VOC Acrylic
1.0 mil Clear PET 1.1 mil
800 Series Permanent Low VOC Acrylic
Magnum GraphicMount™ A-882 tape is a premium self-wound, double-coated polyester film on a 76# ploy-coated paper liner. The clear polyester carrier film is coated on both sides with an aggressive acid-free Low VOC Acrylic pressure-sensitive adhesive. Available in a variety of stock widths.

A-892

PREMIUM

PDF

76#
PCK
1.1 mil
800 Series Permanent Low VOC Acrylic
1.4 mil White PET 1.1 mil
800 Series Permanent Low VOC Acrylic
Magnum GraphicMount™ A-892 tape is a premium self-wound, double-coated polyester film on a 76# ploy-coated paper liner. The white polyester carrier film is coated on both sides with an aggressive acid-free Low VOC Acrylic pressure-sensitive adhesive. Available in a variety of stock widths.

DOUBLE-COATED DIFFERENTIAL TAPES

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
900 Series

D-942

PDF



76#
PCK
0.8 mil
Permanent Rubber
0.5 mil Clear PET 2.0 mil
400 Series Permanent Rubber
A differential self-wound, double-coated removable rubber/permanent rubber tape. The liner side is coated with a rubber-based removable adhesive that allows for clean and easy removability. The airside is coated with aggressive permanent rubber adhesive with excellent initial tack and adhesion to various difficult substrates, including low surface energy plastics. Ideal for bonding to polyethylene foams and the polyester carrier provides exceptional dimensional stability for die-cutting applications.

D-944

PDF


76#
PCK
1.5 mil
Permanent Rubber
0.5 mil Clear PET 2.0 mil
400 Series Permanent Rubber
A differential self-wound, double-coated removable rubber/permanent rubber tape. The liner side is coated with
a rubber-based removable adhesive that allows for clean
and easy removability. The airside is coated with aggressive permanent rubber adhesive with excellent initial tack and adhesion to various difficult substrates, including low surface energy plastics. Ideal for bonding to polyethylene foams and the polyester carrier provides exceptional dimensional stability for die-cutting applications.
*Most common liner is listed for each configuration; additional liner is available.
