Registered ISO 9001: 2015

For Design & Manufacture of Pressure Sensitive Adhesive Tapes & Films

Magnum Tapes and Films Tried & Trusted Tape Specifications

Magnum Tapes and Films Adhesive Product Guide Specs Qualification

Magnum’s Tried & Trusted PSA tapes are ready for your application.

Magnum Tapes & Films supplies customers with a comprehensive selection of well-known pressure-sensitive adhesive tapes. TRIED & TRUSTED adhesive tapes are our most popular rubber and acrylic tapes and are consistently in stock. Due to their versatility, these tapes are suitable for a wide variety of applications. Our highly skilled sales and technical teams are ready to help you select the best adhesive for your most challenging and exciting applications.

Magnum Tapes and Films Tried & Trusted Tapes double coated and differential coated construction

Request Samples   Call Us   Contact Us

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
200 Series

R-213

PDF

76#
PCK
1.3 mil
200 Series Permanent Rubber
0.5 mil Clear PET 1.3 mil
200 Series Permanent Rubber
200 Series is an aggressive rubber foam bonding adhesive that adheres well to ether and ester polyurethane and polyethylene foams. This adhesive is more conformable to a wide range of irregular and uneven substrates. Sticks to anything rough.

R-240

PDF

76#
PCK
2.0 mil
200 Series Permanent Rubber
0.5 mil Clear PET 2.0 mil
200 Series Permanent Rubber


R-241

PDF

76#
PCK
3.0 mil
200 Series Permanent Rubber
0.5 mil Clear PET 3.0 mil
200 Series Permanent Rubber

300 Series

R-382

PDF

76#
PCK
1.1 mil
300 Series Permanent Rubber
1.0 mil Clear PET 1.1 mil
300 Series Permanent Rubber
300 Series rubber is used for mounting tapes for graphic arts, digital printing, POP displays, and wide format mounting. This low-surface-energy rubber has a high bonding strength, making it ideal for gator foam and gator board. It provides high-quality and long-lasting performance for demanding image-mounting applications.

R-392

PDF

76#
PCK
1.1 mil
300 Series Permanent Rubber
1.4 mil White PET 1.1 mil
300 Series Permanent Rubber

400 Series

R-428

PDF

76# PCK

1.1 mil
400 Series Permanent Rubber
0.5 mil Clear PET 1.1 mil
400 Series Permanent Rubber
400 Series is a versatile permanent rubber tape. Ideal for smooth surfaces where a heavy adhesive thickness is not required. The right balance of economy and performance. Excellent bonding to polyethylene, polyisoprene, polystyrene, polypropylene, EPDM, metals, papers, and other flat surfaces. Good dimensional stability with excellent die-cutting performance. Very high shear properties and high peel performance. Available with a tighter release liner, ideal for converting.

R-435

PDF

76# PCK

2.6 mil
400 Series Permanent Rubber
0.5 mil White PET 2.6 mil
400 Series Permanent Rubber


R-449

PDF

76#
PCK
2.1 mil
400 Series Permanent Rubber
0.5 mil Clear PET 1.2 mil
400 Series Permanent Rubber

500 Series

R-502

PDF

Red
PET
1.8 mil
500 Series Permanent Rubber
0.5 mil Clear PET 1.8 mil
500 Series Permanent Rubber
500 Series is a versatile foam bonding adhesive for polyethylene, rubber, and EPDM foams. Aggressive initial tack with excellent peel and surface wet-out. Superb adhesive for irregular and hard-to-stick surfaces such as polyethylene foam. A PET carrier provides exceptional dimensional stability in die-cutting with a standard lay-flat liner—an excellent adhesive for case applications and available as a transfer tape.

R-511

PDF

54#
SCK
1.3 mil
500 Series Permanent Rubber
4.5 mil Crepe 1.3 mil
500 Series Permanent Rubber

600 Series

A-613

PDF



76#
PCK
1.3 mil
600 Series Permanent Low VOC Acrylic
0.5 mil Clear PET 1.3 mil
600 Series Permanent Low VOC Acrylic
600 Series is an excellent option for bonding various complex materials and surfaces, such as polyurethane foams, TPO materials, ABS, Polyethylene, Polypropylene, and powder-coated materials. The 600 Series is a standard lay-flat liner, an LSE adhesive that is conformable with excellent wet-out properties. Low VOC properties meet JIS-A 1901 standards.

A-624

PDF



76#
PCK
2.0 mil
600 Series Permanent Low VOC Acrylic
0.5 mil Clear PET 2.0 mil
600 Series Permanent Low VOC Acrylic

800 Series

A-805

PDF



76#
PCK
1.3 mil
800 Series Permanent Low VOC Acrylic
0.5 mil Clear PET 1.3 mil
800 Series Permanent Low VOC Acrylic
800 Series is a versatile permanent acrylic transfer tape. It is a stiff adhesive with exceptional die-cutting performance. Excellent adhesion to plasticized PVCs, metals, and LSE plastics. Conformable to irregular surfaces with superior outdoor performance. High shear with moderate peel and high-temperature performance. Low VOC 800 Series properties meet JIS-A 1901 standards, are acid-free, and have a neutral pH for archival applications. Meets the ISO 18916 standard for photographic archiving.

A-808

PDF



76#
PCK
2.0 mil
800 Series Permanent Low VOC Acrylic
0.5 mil Clear PET 2.0 mil
800 Series Permanent Low VOC Acrylic


A-811

PDF



Red
PET
3.5 mil
800 Series Permanent Low VOC Acrylic
0.5 mil Clear PET 3.5 mil
800 Series Permanent Low VOC Acrylic

900 Series

D-935

PDF



76#
PCK
1.4 mil
400 Series Permanent Rubber
0.5 mil Clear PET 2.0 mil
200 Series Permanent Rubber
900 Series tapes are differential tapes with a different adhesive on each side. They are available in Rubber/Rubber, Acrylic/Acrylic, and Acrylic/Rubber configurations. We can mix and match our rubber and acrylic adhesives to fit a specific need.

D-939

PDF

76#
PCK
1.1 mil
400 Series Permanent Rubber
0.5 mil Clear PET 1.8 mil
200 Series Permanent Rubber


D-942

PDF

76#
PCK
0.8 mil
100 Series Permanent Rubber
0.5 mil Clear PET 2.0 mil
200 Series Permanent Rubber
 Standard Removable Adhesive

D-947

PDF

76#
PCK
0.8 mil
100 Series Permanent Rubber
0.5 mil Clear PET 2.0 mil
200 Series Permanent Rubber
Ultra-Removable Adhesive

*The most common liner is listed for each configuration; additional liners are available.
