Gasket PSA Tapes

Magnum Tapes & Films® has developed high-performance tapes designed especially for multi-surface bonding applications. Configurations are available with rubber and Low VOC acrylic-based adhesive systems in double-coated and differential-coated construction.

Magnum Tapes and Films PSA Tapes for Gaskets double coated and differential coated construction

Adhesive Gasket Tape FAQs

  • What is gasket tape? Gasket tape is an adhesive-backed flexible tape designed to bond two surfaces. Gasket tape helps ensure that gaskets are properly sealed.
  • How to use gasket tape?
  1. Clean the surfaces prior to application
  2. Measure the gasket tape and ensure it is slightly oversized to the area you need to cover
  3. Apply divider gasket bar
  4. Remove adhesive backing
  5. Firmly press the end of the gasket


DOUBLE-COATED TAPES

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
400 Series

R-449

PDF

60#
SCK
2.1 mil
400 Series Permanent Rubber
0.5 mil Clear PET 1.2 mil
400 Series Permanent Rubber
Permanent pressure-sensitive double-coated general-purpose rubber tape with excellent peel-and-tear performance. Airside provides a thicker glue coating for rougher surface applications. Typically used for bonding to paper, metal, EPDM, polyisoprene, plastics, abrasive pads, and most low or unplasticized substrates. Polyester carrier provides excellent dimensional stability for die-cutting applications.
500 Series

R-501

PDF

60#
SCK
1.4 mil
500 Series Permanent Rubber
0.5 mil Clear PET 1.4 mil
500 Series Permanent Rubber
Versatile foam bonding adhesive. Excellent for bonding polyethylene, rubber, and EPDM foams. Aggressive initial tack with excellent peel and surface wet-out. Thicker adhesive for rough surfaces. PET carrier provides good dimensional stability in die-cutting. Standard layflat liner.

R-502

PDF

60#
SCK
1.8 mil
500 Series Permanent Rubber
0.5 mil Clear PET 1.8 mil
500 Series Permanent Rubber
Permanent pressure-sensitive double-coated rubber tape with excellent peel and good shear performance. Both the air and liner sides provide a heavier glue thickness for the more challenging foam-to-foam bonding applications. Typically used for bonding EPDM, polyurethane, polyisoprene, polyethylene, and other closed-cell foams. Polyester carrier provides excellent dimensional stability for die-cutting applications.

R-508

PDF

60#
SCK
1.4 mil
500 Series Permanent Rubber
0.5 mil Clear PET 3.0 mil
500 Series Permanent Rubber
Versatile foam bonding adhesive. Excellent for bonding polyethylene, rubber, and EPDM foams. Aggressive initial tack with excellent peel and surface wet-out. Premium adhesive for irregular and hard-to-stick surfaces such as polyurethane foam. PET carrier provides good dimensional stability in die-cutting. Standard layflat liner. Excellent adhesive for case applications.
600 Series

A-613

PDF

76#
PCK
1.3 mil
600 Series Permanent Low VOC Acrylic
0.5 mil Clear PET 1.3 mil
600 Series Permanent Low VOC Acrylic
LSE adhesive. Excellent wet-out and bond to various difficult materials and surfaces such as polyurethane foams, TPO materials, ABS, Polyethylene, Polypropylene, and powder-coated materials. PET carrier provides good dimensional stability in die-cutting. Standard layflat liner.

A-624

PDF

76#
PCK
2.0 mil
600 Series Permanent Low VOC Acrylic
0.5 mil Clear PET 2.0 mil
600 Series Permanent Low VOC Acrylic
LSE adhesive. Excellent wet-out and bond to various difficult materials and surfaces such as polyurethane foams, TPO materials, ABS, Polyethylene, Polypropylene, and powder-coated materials. PET carrier provides good dimensional stability in die-cutting. Standard layflat liner.

DOUBLE-COATED DIFFERENTIAL TAPES

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
900 Series

D-902

PDF

60#
SCK
1.4 mil
400 Series Permanent Rubber
0.5 mil PET 1.6 mil
500 Series Permanent Rubber
Differential rubber tape. The liner side provides a general-purpose adhesive. Airside is coated with adhesive for bonding EPDM, polyurethane, polyisoprene, polyethylene, and other closed-cell foams.

D-932

PDF

60#
SCK
1.4 mil
400 Series Permanent Rubber
0.5 mil Clear PET 1.6 mil
300 Series Permanent Rubber
Permanent differential pressure-sensitive double-coated rubber tape with excellent peel and good shear performance. The liner side is coated with general-purpose glue for bonding to paper, metal, EPDM, polyisoprene, plastics, and most low or unplasticized substrates. Airside is coated with glue for bonding ether and ester polyurethane foams. Polyester carrier provides excellent dimensional stability for die-cutting applications.

D-933

PDF

76#
SCK
1.4 mil
400 Series Permanent Rubber
0.5 mil Clear PET 1.8 mil
300 Series Permanent Rubber
Permanent differential pressure-sensitive double-coated rubber tape with excellent peel and good shear performance. The liner side is coated with general-purpose glue for bonding to paper, metal, EPDM, polyisoprene, plastics, and most low or unplasticized substrates. Airside is coated with a heavier glue thickness for bonding ether and ester polyurethane foams. Polyester carrier provides excellent dimensional stability for die-cutting applications.

D-935

PDF

76#
PCK
1.4 mil
400 Series Permanent Rubber
0.5 mil Clear PET 2.0 mil
200 Series Permanent Rubber
A differential, self-wound, double-coated polyester film on a 76# poly-coated kraft paper liner. Coated film on both sides with an aggressive, permanent rubber-based pressure-sensitive adhesive. A general-purpose rubber adhesive on the liner side bonds to a wide variety of substrates. The aggressive rubber adhesive on the airside is excellent for bonding to polyethylene and polyurethane foams.

TRANSFER TAPES

Product Liner* Adhesive Attributes
300 Series

R-302

PDF

76#
PCK
2.0 mil
300 Series Permanent Rubber
Aggressive permanent rubber adhesive with excellent initial tack and adhesion to a variety of difficult substrates. Excellent for ether and ester polyurethane foams. This transfer tape is conformable to uneven surfaces and comes on a standard layflat liner.
500 Series

R-510

PDF

76#
SCK
2.0 mil
500 Series Permanent Rubber
Extended liner aggressive permanent rubber adhesive. Excellent for bonding corrugated and packaging materials. Aggressive initial tack with excellent peel and surface wet-out. Dry edge for easy liner removal. Standard layflat liner.
600 Series

A-602

PDF

76#
PCK
2.0 mil
600 Series Permanent Low VOC Acrylic
LSE adhesive. Excellent wet-out and bond to various difficult materials and surfaces such as polyurethane foams, TPO materials, ABS, Polyethylene, Polypropylene, and powder-coated materials. Conformable. Standard layflat liner.
800 Series

A-802

PDF

76#
PCK
2.0 mil
800 Series Permanent Low VOC Acrylic
Versatile permanent acrylic transfer tape. Stiff adhesive for good die-cutting performance. Excellent adhesive to plasticized PVCs, metals, and LSE plastics. Very conformable to irregular surfaces. Superior outdoor performance. The adhesive is high shear with a moderate peel—excellent high-temperature performance.
*Most common liner is listed for each configuration; additional liner is available.
