Registered ISO 9001: 2015

Magnum Tapes and Films Packaging Tapes and Films



Magnum Tapes and Films Adhesive Product Guide Specifications and Qualifications

Packaging PSA Tapes

Magnum Tapes & Films® has developed a self-adhesive specialty tape suitable for many substrates, including polyethylene and polypropylene. The absence of a carrier is more conformable to a wide range of irregular and uneven substrates — ideal for finger-lift applications, bag sealing, hang tab, and manufacturing.

Magnum Tapes and Films Packaging PSA Tapes for polyethylene and polypropylene

TRANSFER TAPES

Product Liner* Adhesive Attributes
500 Series

R-510

PDF

76#
PCK
2.0 mil
500 Series Permanent Rubber
Extended liner aggressive permanent rubber adhesive. Excellent for bonding corrugated and packaging materials. Aggressive initial tack with amazing peel and surface wet-out. Dry edge for easy liner removal. Standard layflat liner.

HANG TAB TRANSFER TAPES

Product Liner* Adhesive Attributes
200 Series

R-202

PDF

76#
PCK
2.0 mil
200 Series Permanent Rubber
Permanent rubber adhesive with aggressive initial tack and adhesion is excellent for many substrates, including ether and ester polyurethane and polyethylene foams. This finger-lift transfer tape is more conformable to a wide range of irregular and even substrates due to a carrier's absence.
800 Series

A-802

PDF

76#
PCK
2.0 mil
800 Series Permanent Low VOC Acrylic
Versatile finger-lift permanent acrylic transfer tape. Stiff adhesive for good die-cutting performance. Excellent adhesive to plasticized PVCs, metals, and LSE plastics. Very conformable to irregular surfaces. Great outdoor performance. The adhesive is high shear with a moderate peel—excellent high-temperature performance.

DOUBLE-COATED TAPES

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
600 Series

A-610

PDF

76#
PCK
2.0 mil
600 Series
Permanent Low VOC Acrylic
1.0 mil Tissue 2.0 mil
600 Series Permanent Low VOC Acrylic
With quick initial tack and good dimensional stability, the double coated tissue tape is excellent for bonding various difficult materials and surfaces such as foams and LSE plastics. The double-sided tissue tape provides more conformability and stability than a transfer tape. The Low VOC acrylic adhesive withstands higher temperatures and meets the JIS-A 1901 standard for 13 substances of concern.

DOUBLE-COATED DIFFERENTIAL TAPES

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
900 Series

D-942

PDF

76#
PCK
0.8 mil
Permanent Rubber
0.5 mil Clear PET 2.0 mil
400 Series Permanent Rubber
A differential self-wound, double-coated removable rubber/permanent rubber tape. The liner side is coated with a rubber-based removable adhesive that allows for clean and easy removability. The airside is coated with aggressive permanent rubber adhesive with excellent initial tack and adhesion to various difficult substrates, including low surface energy plastics. Ideal for bonding to polyethylene foams and the polyester carrier provides exceptional dimensional stability for die-cutting applications.

D-944

PDF

76#
PCK
1.5 mil
Permanent Rubber
0.5 mil Clear PET 2.0 mil
400 Series Permanent Rubber
A differential self-wound, double-coated removable rubber/permanent rubber tape. The liner side is coated with
a rubber-based removable adhesive that allows for clean
and easy removability. The airside is coated with aggressive permanent rubber adhesive with excellent initial tack and adhesion to various difficult substrates, including low surface energy plastics. Ideal for bonding to polyethylene foams and the polyester carrier provides exceptional dimensional stability for die-cutting applications.
*Most common liner is listed for each configuration; additional liner is available.
