Scrim Tape

Initially developed as reinforcement between paper layers in packaging material, scrim has proven to be a versatile product with diverse custom applications. It's the right material for reinforcing many industrial products like roofing, carpets, air ducts, filters, tape, laminations, and the list goes on. You may have a product that could benefit from scrim versatility.

Request Samples   Call Us   Contact Us

Magnum Tapes and Films SCRIM reinforced adhesives tapes

Scrim Tape FAQs

  • What is scrim tape? Srim tape is a self-wound, double-coated woven tape designed for challenging applications. It has excellent, quick adhesion for permanent bond applications.
  • What is scrim tape used for? Srim tape can be used for a variety of applications but is often used in plastering to secure joints between plasterboard sheets.
  • What does scrim tape do? Srim tape has woven fibers that help to strengthen plasterboard joints by eliminating any gaps that may be found. It should be used after you have applied your first layer of plasterboard and before you apply skim. It can also be used to help fill cracks before you re-apply a skim coating.
  • How do I apply scrim tape? When using scrim tape for plasterboard, you will want to follow these steps to apply it.
  1. Work vertically
  2. Start at the top of the plasterboard
  3. Stick about 3 inches of tape to the plasterboard
  4. Ensure the joint is aligned with the middle of the tape
  5. Once you have the initial tape down, continue to apply the scrim tape by pressing firmly as you apply
  6. Once you get to the end of the plasterboard, use a knife to cut the tape straight.



DOUBLE-COATED TAPES

Product Liner* Liner Side Adhesive Carrier Air Side Adhesive Attributes
200 Series

R-236

PDF

60#
SCK
2.5 mil
200 Series Permanent Rubber
Woven scrim carrier 2.5 mil
200 Series Permanent Rubber
Scrim-reinforced tape is a self-wound, double-coated woven scrim carrier on a 60# silicone-coated densified kraft paper liner. This product is designed for challenging applications and has excellent quick adhesion for permanent bond applications on plastics, metals, non-wovens, felts, and foams, including polyurethane, polyester, neoprene, polyethylene, and EPDM. Magnum’s scrim-reinforced tapes have a high level of peel adhesion, initial tack, and bond to a wide variety of materials.
*The most common liner is listed for each configuration; additional liners are available.
