Automotive Tapes for High-Performance Applications

Magnum Tapes & Films^® is a state-of-the-art manufacturer of high-performance adhesive tape systems specifically engineered for automotive applications. With a focus on quality, durability, and precision, Magnum Tapes & Films delivers adhesive solutions that meet the rigorous demands of the automotive industry. Our adhesive tapes are designed to enhance capability and improve the overall performance of your product designs, ensuring reliability in even the most challenging environments.

Tailored Adhesive Solutions for the Automotive Industry

In the competitive automotive market, where performance and reliability are paramount, Magnum Tapes & Films stands out as a trusted partner. Our advanced adhesive technologies cater to a wide array of automotive applications, providing solutions that support sound dampening, insulation, cushioning/padding, and sealing functions. These capabilities are critical in enhancing modern vehicles’ comfort, safety, and longevity.

Our adhesive systems are built to withstand extreme conditions, ensuring that components remain secure and functional under stress. Whether you need tapes for bonding, mounting, or protection, Magnum Tapes & Films offers a comprehensive range of products that can be customized to meet specific application requirements.


Rubber and Acrylic Adhesive Systems

At the core of our automotive tapes are our rubber and acrylic adhesive systems, which offer distinct advantages depending on the application.

Rubber Adhesive Systems: Known for their strong initial tack and excellent adhesion to various substrates, rubber adhesives are ideal for applications where immediate bonding strength is critical. These systems are particularly effective in areas requiring a robust, long-lasting hold, such as in gasket applications and other sealing needs.

Low-VOC Acrylic Adhesive Systems: Acrylic adhesives are valued for their long-term stability and resistance to environmental factors such as UV light, heat, and chemicals. These adhesives maintain their performance over time, making them suitable for applications where durability and endurance are crucial. For example, acrylic-based tapes are often used in mounting and insulating applications where exposure to harsh conditions is expected.

Both adhesive systems are available in double-coated and double-coated differential configurations, providing versatility in application. The double-coated tapes feature adhesive on both sides, making them perfect for bonding two surfaces together, while the double-coated differential tapes offer different adhesive strengths on each side, catering to specific bonding requirements.


Product	Liner*	Liner Side Adhesive	Carrier	Air Side Adhesive	Attributes
600 Series
A-610 PDF	76# PCK	2.0 mil 600 Series	1.0 mil Tissue	2.0 mil  600 Series	With quick initial tack and good dimensional stability, the double-coated tissue tape is excellent for bonding difficult materials and surfaces, such as foams and LSE plastics. The double-sided tissue tape provides more conformability and stability than transfer tape. The low-VOC acrylic adhesive withstands higher temperatures and meets the JIS-A 1901 standard for 13 substances of concern.
A-624 PDF	76# PCK	2.0 mil 600 Series	0.5 mil Clear PET	2.0 mil 600 Series	LSE adhesive. Excellent wet-out and bond to difficult materials and surfaces such as polyurethane foams, TPO materials, ABS, polyethylene, polypropylene, and powder-coated materials. PET carriers provide good dimensional stability in die-cutting. Standard layflat liner.
A-675 PDF	12PT Board	2.2 mil 600 Series	0.5 mil Clear PET	1.9 mil 600 Series	LSE adhesive. Excellent wet-out and bond to difficult materials and surfaces such as polyurethane foams, TPO materials, ABS, polyethylene, polypropylene, and powder-coated materials. PET carriers provide good dimensional stability in die-cutting.

DOUBLE-COATED DIFFERENTIAL TAPES

Product	Liner*	Liner Side Adhesive	Carrier	Air Side Adhesive	Attributes
900 Series
D-935 PDF	76# PCK	1.4 mil 400 Series	0.5 mil Clear PET	2.0 mil 200 Series	A differential, self-wound, double-coated polyester film on a 76# poly-coated kraft paper liner. Coated film on both sides with an aggressive, permanent rubber-based pressure-sensitive adhesive. A general-purpose rubber adhesive on the liner side bonds to a wide variety of substrates. The aggressive rubber adhesive on the airside is excellent for bonding to polyethylene and polyurethane foams.
D-950 PDF	76# PCK	2.1 mil 200 Series	0.5 mil Clear PET	2.1 mil 800 Series	Permanent differential pressure-sensitive double-coated rubber/acrylic tape. The liner side is coated with aggressive permanent rubber adhesive with excellent initial tack and adhesion to various difficult substrates. Excellent for bonding to polyethylene foams. The polyester carrier provides excellent dimensional stability for die-cutting applications. The air side is coated with a permanent pressure-sensitive acrylic adhesive with excellent peel adhesion and wet-out to various substrates, including low-surface-energy plastics. Excellent resistance to aging and ultra-violet light.
D-956 PDF	80# SCK	1.8 mil 500 Series	0.5 mil Clear PET	2.0 mil 600 Series	A differential, self-wound polyester film on an 80# SCK liner. The airside of the polyester film is coated with an aggressive, higher shear, high peel, and low-VOC acrylic-based pressure-sensitive adhesive. The liner side is coated with an aggressive, permanent rubber-based pressure-sensitive adhesive. This aggressive rubber adhesive is excellent for bonding to polyethylene and polyurethane foams.
D-973 PDF	76# PCK	2.0 mil 800 Series	0.5 mil Clear PET	2.0 mil 600 Series	Permanent differential pressure-sensitive double-coated acrylic/rubber tape with excellent peel and good shear performance. The liner side is coated with general-purpose rubber glue for bonding to paper, metal, EPDM, polyisoprene, plastics, and most low- or unplasticized substrates. Airside is coated with an LSE acrylic adhesive with excellent wet-out and bonding to various complex materials and surfaces, such as polyurethane foams, TPO materials, ABS, polyethylene, polypropylene, and powder-coated materials. The polyester carrier provides excellent dimensional stability for die-cutting applications.

*The most common liner is listed for each configuration; additional liners are available.

Tested and Proven Performance

Magnum Tapes & Films is committed to delivering products that not only meet but exceed industry standards. Our automotive tapes have undergone rigorous testing to ensure they perform under the most demanding conditions.

We are proud to have passed the General Motors heat and humidity testing, which evaluates the tape’s ability to withstand extreme temperatures and moisture levels. This ensures that our tapes can maintain their integrity and adhesion in environments where temperature fluctuations and humidity are a concern.

In addition, our tapes have successfully met the Toyota TSK6712G test specification, a stringent standard that further confirms the reliability and quality of our products. This specification tests the tape’s performance in various conditions, including its resistance to heat, cold, and chemical exposure. Meeting this standard is a testament to the durability and effectiveness of Magnum Tapes & Films’ adhesive solutions in real-world automotive applications.

Comprehensive Capabilities

Magnum Tapes & Films is more than just a supplier; we are a full-service partner dedicated to supporting our clients throughout the product development process. From initial design to final application, our team of experts works closely with customers to develop adhesive solutions that meet their specific needs.

Our manufacturing facilities are equipped with the latest technology, allowing us to produce tapes that are consistent in quality and performance. Whether you need a standard product or a custom solution, Magnum Tapes & Films has the capabilities to deliver.

Why Choose Magnum Tapes & Films?

Choosing Magnum Tapes & Films for your automotive tape needs means partnering with a company that values innovation, quality, and customer satisfaction. Our commitment to excellence is reflected in every product we manufacture, ensuring that you receive adhesive solutions that enhance the performance of your projects.

Whether you want to improve sound dampening, insulation, cushioning, or sealing, Magnum Tapes & Films offers the right adhesive solution for your application. Trust in our expertise and proven track record to provide tapes that perform reliably under the most demanding conditions.

Contact us today to learn how Magnum Tapes & Films can support your automotive projects with our high-performance adhesive tape systems.

Contact us to discuss your needs; we’re here to help!
